RB990
- Move dirt, grade driveways, and clear snow
- Available as fully hydraulic, fully manual or a combination of cylinder options
- Fully hydraulic models allow precise blade and material control (angle, tilt and offset)
- Tough, dozer-type full box construction
- Three-point hitch: CAT 2 and 3
Specifications
| Tractor Engine (HP) |
80-150 |
|---|---|
| Tractor Hitch |
CAT 2 and CAT 3 |
| Working Width (in) |
107 |
| Approximate Weight (lbs) |
1,483 |
| Moldboard Height (in) |
18 |
| Moldboard Thickness (in) |
0.25 |
| Reversible Cutting Edge Dimensions (in) |
0.5 x 6 |
| ASABE Quick-hitch Compatible |
Yes |
| Parking Stand |
Standard |
| Angle Adjustments |
up to 60 degrees (hyd) |
| Tilt Adjustment |
up to 28 degrees (mech or hyd) |
| Offset (in) |
up to 33 (mech or hyd) |
| Tailwheel |
Optional |
