Grading Scrapers
GS54.30
Standard Plus
Easy Connection
Engineered Quick-Hitch Ready from the factory. No additional hardware is required to use your quick hitch, so you can get in the field and get to work.
Durability
Heavy-duty saddle scarifier mounting, approachable leading edges and structural reinforcements keeps Woods scrapers stronger for longer.
Versatility
Available in a variety of widths and up to 16″ box height.
Read More
Additional Features
- Engineered Quick-Hitch Ready from the factory. No additional hardware is required to use your quick hitch, so you can get in the field and get to work.
- Heavy-duty Mast Plate creates more down force for a smoother surface – all but eliminating a “washboard” effect.
- Adjustable Scarifier Teeth with replaceable tips for durability and versatility.
- Tall Side Frames hold more material for leveling.
- Reversible/Replaceable High-carbon Cutting Edges give you control to better match your application.
- Adjustable Skid Shoes allows operator to set the grade.
Specifications
| Product Tier |
Standard Plus |
|---|---|
| Tractor Engine (HP) |
20-45 |
| Tractor Hitch |
Limited CAT 1 and CAT 1 |
| Working Width (in) |
54 |
| Overall Length (in) |
42 |
| Box Height (in) |
14 |
| No. of Scarifiers |
4 |
| Weight (lbs) |
430 |
| Scarifier Depth |
0, 1, 2.5 |
| Cutting Edges |
(2) .5 x 6 |
| Woods C® |
Tractor Compatibility
| Tractor Make | Tractor Model |
|---|---|
| Tractor Make | Tractor Model |
| Loading... | |
Mike Wilde –
I have been very happy with the grading scraper. Super easy to use and well built. I did have a flaw/crack in the main beam and even though my product was 2 months out of the one year warranty, Woods stood behind their product. A couple pictures and my local dealer facilitated everything. Buy American, and have local support. Could not be happier. Buy once, cry once!
