Discontinued
Discontinued
FPS48
- Plant up to three different seeds at two different depths: Shallow broadcast and/or deeper rows
- Three seed box choices: One cool season and two legume
- All seed boxes can be engaged/disengaged independently, with a single lynch pin – no tools required
- Easily and accurately adjust seeding rates with a single lever
- ASABE quick-hitch compatibility ensures faster, easier and safer hook-ups
Specifications
| Tractor Engine (HP) |
25-45 |
|---|---|
| Tractor Hitch |
CAT 1 and 2 |
| Working Width (in) |
49 |
| Drive Type |
Ground |
| Number of Seed Boxes Available |
3 |
| Seed Metering |
6 seed cups |
| Seed Box Ratio |
5.1:1 or 14.4:1 |
| Cool Season Seed Box with Agitator |
Standard |
| Legume Seed Box |
2 optional |
| Legume Seed Box Capacity (bushel) |
1 |
| Calibration Tray |
Standard |
| Crank Handle |
Standard |
| ASABE Quick Hitch Compatible |
Yes |
| Cast Iron or Nylon Trailing Cultipacker |
Optional (9.5 in diameter cast iron or 11 in diameter nylon) |
| Cool Season Seed Box |
Standard |
| Disc Blades |
(8) Standard, 16 in Notched |
| Frame Platform |
Optional |
| Mud Scrapers |
Optional |
