RB750
- Move dirt, grade driveways, and clear snow
- Available as fully hydraulic, fully manual or a combination of cylinder options
- Fully hydraulic models allow precise blade and material control (angle, tilt and offset)
- Tough, dozer-type full box construction
- Three-point hitch: CAT 2
Specifications
| Tractor Engine (HP) |
50-100 |
|---|---|
| Tractor Hitch |
CAT 2 |
| Working Width (in) |
83 |
| Approximate Weight (lbs) |
1,193 |
| Moldboard Height (in) |
17 |
| Moldboard Thickness (in) |
0.313 |
| Reversible Cutting Edge Dimensions (in) |
0.5 x 6 |
| Skid Shoes |
Optional |
| ASABE Quick-hitch Compatible |
Yes |
| Parking Stand |
Standard |
| Angle Adjustments |
9 forward up to 60 degrees; 5 reverse up to 30 degrees (mech or hyd) |
| Tilt |
up to 30 degrees (mech or hyd) |
| Offset (in) |
up to 24 (mech or hyd) |
| End Plates |
Optional |
| Tailwheel |
Optional |
