Some colors only available on select models.
Batwing® Cutters
New
BW10.72
Extra Heavy-Duty
#1 In Cut Quality
Enabled by deep cutting decks, high-lift blades, and new features like Woods Exclusive Level Lock™ Technology that ensures a more level cut height across rugged terrain.
Read Cut Quality Study.
Easy Maintenance
EZ-Change™ Blade System allows blade change in five steps with a 3/4″ wrench. No impact gun or torch required.
Easy Connection
The Woods Exclusive Smartlift™ System holds holds your 80lb PTO driveline allowing you to easily connect and disconnect from the tractor.
Unmatched Gearbox PROTECTION
10-year warranty including parts, labor, and seals. Gearbox also features Woods Exclusive Cool-Flow™ Lubrication System and Triple Seal™ Gearbox Protection. See how it works.
Read More
Additional Features
- Woods® Level Lock™ Technology ensures a more level cut height across rugged terrain. (patent pending)
- Optional Cut Height Indicator allows the operator to mark a desired cut height prior to mowing and readjust from the cab as needed for a more even cut.
- The Woods Exclusive Smartlift™ System holds holds your 80lb PTO driveline allowing you to easily connect and disconnect from the tractor.
- Large Blade Access Window for easy blade maintenance from the top of the deck.
- Hose Holder holds hoses closer to the hydraulic remotes clear of the PTO shaft and tractor tires.
- Thumbscrew Dipstick quickly and easily check gearbox oil.
- PTO Lock Collar holds PTO collar back for easier tractor connection.
- Magnetic Driveline Shields lift to service gearbox.
- Aligned Grease Points easily find and service grease points.
Backed by a 10-year warranty including parts, labor, and seals.
Specifications
| Product Tier |
Extra Heavy-Duty |
|---|---|
| Tractor PTO HP |
65-300 |
| Tractor PTO (rpm) |
540 or 1,000 |
| Hitch Type |
Swivel clevis hitch |
| Adjustable Cutting Height (in) |
2 to 15 |
| Cutting Capacity Diameter (in) |
4.5 |
| Cutting Width (ft) |
10 |
| Cutting Area Shielding |
Single or Double Chain |
| Blade Tip Speed (fpm) |
15,526 (wing), 16,286 (center) at 540 rpm 15,708 (wing), 16,132 (center) at 1,000 rpm |
| Blade Size (in) |
.5 x 4 |
| Tongue Weight (lbs) |
2,410 |
| Transport Width (in) |
93 |
| Hydraulics Wing Flex (degrees) |
90 up, 22 down |
| Side Skirt (in) |
.25 thick x 13 deep |
| Stump Jumper Type |
Round |
| Deck Thickness (in) |
0.18 |
| Wheel Type |
21 in. laminated, 25 in. severe-duty Ag, 25 in. severe-duty Ag foam-filled, 27 in. severe-duty Ag foam-filled, 29 in. used aircraft |
| Driveline Rating |
CAT 6 CV main, CAT 5 wing |
| Gearbox Rating (hp) |
275 splitter / 225 center and wing |
| Gearbox Warranty (yrs) |
10 |
| Output Shaft Size (in) |
3 dia |
| Options |
Double row chain shielding, Dual wheels, Towing Eye, Walking Tandems, Shredding Kit |
| Structure Warranty |
2 years |
