Tractor PTO Speed (rpm) |
540 |
---|---|
Tractor PTO HP |
25-60 |
Shipping Weight (lbs) |
2051 |
Hitch |
CAT 1 Drawbar |
Cutting Width (in) |
144 |
Cutting Height (in) |
1.5 – 4.5 |
Wing Deck Cut Width (in) |
48 |
Center Deck Cut Width (in) |
60 |
Deck Overlap (in) |
6 |
Overall Width (in) |
147 |
Max Overall Length (in) |
141 |
Transport Width (in) |
91 |
Transport Length (in) |
135 |
Splitter Gearbox HP |
100 |
Blade Tip Speed (fpm) |
18,000 |
Drive Type |
Gearbox over v-belt |
Input Driveline |
CAT 3 (CV) |
Wing Drivelines |
CAT 3 |
Transport Tires (in) |
(2) 20.5 x 8-10 |
Caster Wheels (in) |
(10) 8 x 3.5 solid |
Wing Deck Lift Cylinders |
3 x 10 single-acting |
Center Deck Lift Cylinders |
3 x 8 single-acting |
Trailer Frame Construction |
4.0 x 4.0 x .25 square tube |
Deck Thickness |
10 gauge |
Blade Spindles |
(9) ductile iron, lubed-for-life |
Blade Dimensions (in) |
(6) .25 x 2.5 x 17.0, (3) .25 x 2.5 x 20.8 |
Hitch Adjustment |
Floating clevis, multi-position |
Transport Lock |
Automatic, manual release |
Transport Tires |
Non-highway speed-rated |
Cut Height Adjustment |
Caster spacers |
Belt Construction |
B-section, Kevlar® |
Belt Cover |
Clutching cover |
Belt Adjustment |
Spring-loaded idler |
Rear Chain Shielding |
Optional |
Anti-Scalp Rollers |
(1) Front and (2) Rear Optional |
Light Kit |
Optional |
Hydraulic Wing Unlock |
Optional |
Gearbox Warranty |
3 year homeowners, 1 year commercial |
Mower Warranty |
1 year |
Spindle Warranty |
1 year |
