Standard
Dynamically balanced auger and impeller for less vibration .
Heavy-duty reinforced housing withstands hard impacts .
Shear bolt protection on driveline for processing heavy snow.
6-year warranty including parts, labor, and seals.
Backed by a 6-year warranty including parts, labor, and seals.
| Product Tier |
Standard |
|---|---|
| PTO Power Requirements (HP) |
20-40 |
| Operating Weight; including chute & hydraulic deflector (lbs) |
540 |
| Working Width (in) |
63 1/2 |
| Working Height (in) |
27 1/2 |
| Overall Width (in) |
64 3/4 |
| Overall Length (in) |
37 3/4 |
| Impeller Diameter (in) |
24 |
| Impeller Width (in) |
7 |
| Impeller (rpm) |
540 |
| Main Auger Diameter (in) |
15 |
| Auger Driven System |
Chain No. 60 |
| Auger (rpm) |
170 |
| Chute Rotation |
Manual or Hydraulic |
| Replaceable and Reversible |
Yes |
| Cutting Edge Dimension (in) |
3/8 x 1 1/2 |
| Main Driving System |
Driveline Series 40 |
| Chain Idler |
Yes |
| Number of Auger Shear Bolt |
1 (on drive shaft) |
| Number of Impeller Shear Bolt |
1 (on driveline) |
| Type of Hitch |
3 pts. CAT 1 |
| Parking Stand |
Standard |
| Gearbox Warranty |
6-years Includes Seals |
