Batwing® Cutters
New
BW15.72
Extra Heavy-Duty
#1 In Cut Quality
Enabled by deep cutting decks, high-lift blades, and new features like Woods Exclusive Level Lock™ Technology that ensures a more level cut height across rugged terrain.
Read Cut Quality Study.
Easy Maintenance
EZ-Change™ Blade System allows blade change in five steps with a 3/4″ wrench. No impact gun or torch required.
Easy Connection
The Woods Exclusive Smartlift™ System holds holds your 80lb PTO driveline allowing you to easily connect and disconnect from the tractor.
Unmatched Gearbox PROTECTION
10-year warranty including parts, labor, and seals. Gearbox also features Woods Exclusive Cool-Flow™ Lubrication System and Triple Seal™ Gearbox Protection. See how it works.
Read More
Additional Features
- Woods® Level Lock™ Technology ensures a more level cut height across rugged terrain. (patent pending)
- Optional Cut Height Indicator allows the operator to mark a desired cut height prior to mowing and readjust from the cab as needed for a more even cut.
- The Woods Exclusive Smartlift™ System holds holds your 80lb PTO driveline allowing you to easily connect and disconnect from the tractor.
- Large Blade Access Window for easy blade maintenance from the top of the deck.
- Hose Holder holds hoses closer to the hydraulic remotes clear of the PTO shaft and tractor tires.
- Thumbscrew Dipstick quickly and easily check gearbox oil.
- PTO Lock Collar holds PTO collar back for easier tractor connection.
- Magnetic Driveline Shields lift to service gearbox.
- Aligned Grease Points easily find and service grease points.
Backed by a 10-year warranty including parts, labor, and seals.
Specifications
| Product Tier |
Extra Heavy-Duty |
|---|---|
| Tractor PTO HP |
65-300 |
| Tractor PTO (rpm) |
540 or 1,000 |
| Hitch Type |
Swivel clevis hitch |
| Adjustable Cutting Height (in) |
2 to 15 |
| Cutting Capacity Diameter (in) |
4.5 |
| Cutting Width (ft) |
15 |
| Cutting Area Shielding |
Single or Double Chain |
| Blade Tip Speed (fpm) |
15,526 (wing), 16,286 (center) at 540 rpm 15,708 (wing), 16,132 (center) at 1,000 rpm |
| Blade Size (in) |
.5 x 4 |
| Blade Overlap (in) |
6 |
| Weight/Tongue Weight (lbs) |
5,635/2,410 |
| Transport Width (in) |
96 |
| Hydraulics Wing Flex (degrees) |
90 up, 22 down |
| Side Skirt (in) |
.25 thick x 13 deep |
| Stump Jumper Type |
Round |
| Deck Thickness (in) |
0.18 |
| Wheel Type |
21 in. laminated, 25 in. severe-duty Ag, 25 in. severe-duty Ag foam-filled, 27 in. severe-duty Ag foam-filled, 29 in. used aircraft |
| Driveline Rating |
CAT 6 CV main, CAT 5 wing |
| Gearbox Rating (hp) |
275 splitter / 225 center and wing |
| Gearbox Warranty (yrs) |
10 |
| Output Shaft Size (in) |
3 dia |
| Options |
Double row chain shielding, Dual wheels, Towing Eye, Walking Tandems, Shredding Kit |
| Structure Warranty |
2 years |
Trenton Double –
Tough and rugged machines, works amazing through brush.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Unwatch Flag for removal
Barry Stewart –
I replaced my 11 year old BW180XHD with the BW15.72 recently. Actually, if I had made a list of improvements from my old cutter, and build one from the ground up, the 15.72 would be perfect! Some highlights I’d like to share: The Level Lock system is great, and should help keep those wings level in uneven ground, making everything less susceptible to wear and damage, as well as giving a nice level cut. I’m picky about that sort of thing.
The Smartlift is a huge improvement when connecting the main driveshaft to the PTO. I foresee much easier hookups, and less sweating with that. That heavy driveline just slid right on, and locked into place. Other great features are the wing hinge shafts are fitted with very sturdy hinges with lots of grease fittings that grease the entire shaft. The number and location of all grease fittings on the cutter, as well as the chart about when and how much grease to apply are helpful and should prolong the life of this cutter! The added lights and wing lock system are great for how I transport the batwing cutter from project to project! I feel much safer now knowing I have greater visibility to others during transport. Another feature I like is the magnetic shields on the drive line system. Great access, that is quick and easy to access those areas for maintenance, but sturdy and secure when cutting. This cutter runs SMOOTH! I really thought I’d have a break in period with this new cutter where shimmies and shaking because of all the new parts is common, not so with my 15.72! I accidentally had the best example of this smoothness happen the first time I used my cutter.. I had placed a can of spray oil on the front of the center deck of the 15.72, while working on my tractor and forgot I put it there. The next day, I had to use the cutter on 4 acres across the road that needed cutting. When I was blowing the deck off when done, that can of oil was still there!
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Unwatch Flag for removal
Rick Canfield –
The BW15.72 has exceeded all of our expectations. This unit has great cut quality, is easy to maintain and cuts whatever we need it to with ease. The small enhancements such as the hose holder and PTO holder make hooking up the cutter much easier than previous models. We look forward to continuing to use this machine for many years to come.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Unwatch Flag for removal
