| Tractor PTO HP |
30-100 |
|---|---|
| Maximum Digging Depth |
102 (8.5 ft) |
| Thumb |
Optional mechanical or hydraulic |
| Digging Depth - 8 ft Flat Bottom (in) |
82 |
| Reach from Swing Pivot (in) |
141 |
| Loading Height (in) |
83 |
| Loading Reach (in) |
61 |
| Transport Height (in) |
94 |
| Transport Length (in) |
55 |
| Approx. Weight - Frame Only (lbs) |
1,275 |
| Swing Arc (degrees) |
180 |
| Bucket Rotation (degrees) |
180 |
| Stabilizer Spread - Up (transporting) (in) |
71 |
| Stabilizer Spread - Down (operating) (in) |
102 |
| Relief Pressure (psi) |
2,465 |
| Bucket Digging Force (lbs) |
4,600 |
| Dipperstick Digging Force (lbs) |
2,940 |
| Trenching Bucket Widths (in) |
12, 15, 18, 24 |
| Flip-Over Stabilizer Pads |
Standard |
| Stabilizer Street Pads |
Optional |
| PTO Pump Kit |
Optional |
| Cemetery / Bellhole Bucket |
36 |
| Ditching Bucket |
36 |
| 2-Cylinder Swing |
Yes |
| Warranty |
2 year limited, including the tractor |
BH85
- Curved boom offers better visibility and reaches over obstacles with little repositioning
- Extra-long reach and digging depths saves time repositioning
- High digging forces powers through hard, rocky, root-fill ground
- Saw-tooth edges on thumb, dipper and bucket can grip and rip
- Optional mechanical or hydraulic thumb add versatility
- Sub-frame or 3-point hitch mounts are compatible with most loaders and undermount mowers
- Two-year limited warranty covers your tractor
